How to Deploy a Rails 4 App With Git and Capistrano

I think the two key aspects of any deployment process are speed and consistency. Speed means you can iterate and fix bugs fast and keep your production code in sync with your development code. Consistency means you know it's going to do the same thing every time so you're not afraid to actually do it and stay up to date. Using a revision control system like Git along with automated deployment recipes with Capistrano satisfies these criteria easily and gives your Rails app a little more oomph.

This article assumes you're using a setup like I outlined in my article on how to setup a production server. That is, a Unix server with SSH access using Phusion Passenger and Apache serving a Ruby on Rails app.

Knowing is half the battle

Back when I was first learning Rails as a wide-eyed noob, I had no idea how to get from this thing that was working on my dev machine onto a real web server that other people could actual use. All this Unix CLI stuff seemed like black magic to me (probably, partly because my terminal is black) and I felt like I needed a PhD in Rocket Surgery to make it happen. Rails made app development so easy! Surely there was a way of deploying my creations that didn't make my head explode.

Well, there is and there isn't. Services like Heroku are trying to take a lot of the pain out of deploying web apps, and they're doing a good job of it. But when I was trying to learn for the first time I felt those services made even less sense to me TBH. I felt that at least on the CLI, I was in control and could see with my own eyes what was happening (or not happening). And so I slowly picked up some understanding of how my mysterious web server worked and how I could make it do what I wanted.

I did everything manually at first (copying files, migrating databases, installing gems, restarting services). But I quickly found out why nobody does this. First, it's terribly error-prone to be typing all those commands with my clumsy human hands. Second, sometimes things exploded and I didn't know why, and would need to spend hours of figuring out where that one ampersand I missed was. The moral of the story is: figure out how to do it once, then save it in a script that can be repeated flawlessly (computers are apparently really good and doing the same thing over and over again; who knew?). And this is why I use Capistrano and Git.

Your app

You're going to need something to actually deploy. I'm not going to presume to know the awesomeness that is your particular app, so I'm just going to use a simple demo here (the deployment process should pretty much be the same regardless of what's going on in your app). My goal, here, is to explain a very simple (sortof) method for automating your Rails deployments to give you a place to start. This isn't the fastest way or the fanciest way, but it'll make your process consistent, and it will definitely be a lot faster than doing it manually. My thinking is that if it at least works you can afford the time to work your way up to more advanced techniques. This is a post I wish I had myself five years ago!

Here's a little to-do app I made when I tested my server installation (using MySQL because that's what I installed on my server):

rails new todoapp -d mysql
cd todoapp
bundle install
rails g scaffold todo name:string finished:boolean

Edit your database.yml file to configure it for your development and production database, then try it out locally at http://localhost:3000 to make sure it's working properly (test production after deployment).

rake db:migrate
rails s

This hardly does anything useful, but you should be able to make new todos and mark them as "finished". Not the most advanced app, but an app nonetheless.

Git that sh*t under version control!

Before we get into actual deployment, it's pretty important that you get your code into a version control system. Being a human and not a machine, I mess stuff up a lot. I feel a lot better knowing I can always go back to a working version of my code without having to decipher the mess I just made ;) And using a centralized version control system like Git makes it super easy to share your code with your friends so they can help you out. So, first order of business is to gittify your code.

Download Git

There are binaries for various platforms as well as the source code (if you want to compile it yourself). I'm running Mac OS 10.8 on my dev machine and haven't had any issues with the convenient .dmg binary that's available (I'm running Git version 1.7.9.6). It's up to you what works best for your system. The source code is as easy as config, make, make install so don't be scared of it ;)

Once you've got it installed, the first thing to do is configure some settings so Git knows who you are when you make commits.

git config --global user.name "Your name"
git config --global user.email "[email protected]"

Every time you commit some code it will tag your name and email to it in the repository (so, like, if you were participating in some open source badassery and want other badasses to know where that awesome contribution of yours came from, this is how you do it).

With everything setup now you're going to go to your Rails app directory and put it into its own local repository.

cd /your/project/folder
git init
touch .gitignore

After initializing a new Git repository for your app, before you make any commits, the first thing you'll want to do is setup your .gitignore file (Rails generates this for new projects so you probably don't need to make it yourself anymore). This file contains a list of files (and patterns of files) to ignore and not include in your repository. This is useful so you don't include stupid stuff like .DS_Store but also to keep sensitive files like database.yml out of it so you're not storing passwords where everybody (well, those who have access to your repository) can see them. You can include other stuff as you see fit (e.g., I like to exclude any sqlite databases I might be using as well as static asset files that I've generated for testing but which aren't part of my app) but you at least want to add these: database config, Mac junk, log files, and temp files.

/config/database.yml
.DS_Store
/log/*
/tmp/*

Now you can make your first commit and put all your code into the neat little box you just made.

git add .
git commit -m 'first commit'

This adds everything from your current location (which should be your app's root) and commits all those files to the repository. The -m flag is for "message" so you can briefly describe what just happened. Any subsequent changes you make can be added like this and you can log messages of what you did so when you browse your commits you have an idea of what's going on in there.

Remote repository and Github

It's a huge convenience to store your repository in the cloud so other people can access it and contribute, as well as make it easier to run deployments from any computer. This also serves as an offsite backup for all your work (bonus). I store all my projects on Github because it has made this process super easy and has a bunch of really great documentation for when you get stuck. But I've stored my remotes on my own servers in the past, so don't feel obligated to use a paid service if you don't want to. Regardless of how you store your remotes, you're going to need to hookup your local repository to the remote so you can sync the two. Once you've created your remote repository (if you're using Github, read this) save its path as one of your local repository's remotes (this is still from your app's root).

git remote add origin [email protected]:username/your-repo-name.git

or

git remote add origin https://github.com/username/your-repo-name.git

I'm calling the new remote "origin" here, which is just a convention, but you could call it whatever you want.

Next, push your local code to the remote to sync the two together (this command pushes your local master branch to the origin remote):

git push origin master

Git does a lot of other great stuff that you should read about, like forking, branching, merging, and tagging. But I'm just going to leave at that for the sake of this post so we can get our hands dirty with some deployment processes.

Server environment

Add a group to your remote server called "deployers" that will have permissions to deploy to the server and run stuff without requiring full root/sudo access.

sudo groupadd deployers

Create a user (if you haven't already) that will be added to the "deployers" group for making all your deployments. This user should have super-user privileges (I cover creating a new user in my post about server setup). Then add the user you want to use for deployments to that group (the last argument is the username you want to add).

sudo usermod -a -G deployers bill

Then, update permissions on your deployment path where you want your app's code to go (here, I'm assuming the user "bill" owns that path). This will give the "deployers" group read and write access to all files and directories beneath /deploy/to/path.

sudo chown -R bill:deployers /deploy/to/path
sudo chmod -R g+w /deploy/to/path

Capify

Capistrano is a Ruby gem that makes your deployment life a lot easier. I used to manually copy files, logon to my servers, run deployment tasks off the CLI, and usually ended up causing a lot more problems than I was solving because my stupid human hands don't always type everything perfectly. I spent many long nights fixing problems caused by my manual deployment processes. Capistrano changes all this by formalizing and automating these tasks because computers can talk to each other a lot more clearly than you can mash buttons and repeat the same (workable) tasks over and over again with zero errors (well, at least I hope there are zero errors!) You can read more details about setting up Capistrano in the Capistrano Handbook.

Installing Capistrano is as easy as adding it to your app's Gemfile and running bundle install. You don't need it on the production server, so you can just add it under the "development" group in your Gemfile. For reference, I'm using version 2.14.2.

group :development do
  gem 'capistrano'
end

And install with bundler (from your app's root).

bundle install

Once installed, you'll need to "capify" your project. This will generate a few files (namely /config/deploy.rb and /Capfile). The deploy.rb is where you can add or write custom scripts to help automate your deployment tasks and save your carpal tunnel for more important application programming.

cd /path/to/your/project
capify .

Capistrano settings

Once your project is capified, open up your editor of choice and modify /config/deploy.rb (here's the final example). There's a bunch of stuff in there, but first I'm going to focus on the top-most settings, denoted with various set commands.

First, you need to tell Capistrano your app's name and the clone path to your app's remote repository.

set :application, "YourApplicationName"
set :repository, "[email protected]:your-username/your-repository-name.git"

Next, tell it where your app needs to be installed on your production server (this is the path to where you want your app to live, starting from your server's root). The path will be the location you pointed your server to that I covered in my previous post. You can leave this out if you want to deploy to Capistrano's default location of /u/apps/#{ application }.

set :deploy_to, "/path/to/your/app"

Set the type of repository you're using (e.g., GIT, SVN, etc.) and which branch you want to deploy from (usually "master").

set :scm, :git
set :branch, "master"

Set the user you want to use for your server's deploys.

set :user, "bill"

Now, you could use the scm_passphrase setting to tell Capistrano the password to use for your deployment user, but I don't like the idea of storing my server password in a file I want to keep in my repository. This is why I setup my server with RSA keys that allow my dev machine access without the need for entering a password every time. But if you want to put it in your deployment script without using keys, you'd do it like this (although not recommended):

set :scm_passphrase, "password"

I change another setting called use_sudo to false so commands are executed with the user's permissions unless I specify otherwise. If you added your user to the "deployers" group (which has write-access to your app's directory tree) you probably won't need to use sudo much, if at all.

set :use_sudo, false

Set your rails environment (this is deploying to the production server, so I'm setting it to "production", but you might want to deploy to a staging server with a custom environment). You can re-use this variable in your scripts whenever you need to specify the environment so you only need to change it in one place to keep things DRY.

set :rails_env, "production"

Tell Capistrano how you'd like to make updates. There are many different ways of doing it, but for simplicity's sake, I'm going to stick with the most straight-forward method, namely copy. This will clone your entire repository (download it from the remote to your local machine) and then upload the entire app to your server.

set :deploy_via, :copy

You could alternatively use a faster method like remote_cache which will run a fetch from your server to your remote repository and only update what's changed, but that requires some additional authentication between your server and the remote repository. I just want to get you up and running first. Worry about optimizing the process later.

Next, you need to tell Capistrano about any special SSH options it should be aware of. For instance, my server is setup to use a custom port number and uses RSA keys for authentication to my Github account. So, I need to specify the port, and use what's called "agent forwarding" to connect to my remote repository (it sounds weird, but agent forwarding will make your life easier by using your local keys rather than those installed on your server). Read more about agent forwarding with this great article from Github.

set :ssh_options, { :forward_agent => true, :port => 4321 }

You can also specify how many releases Capistrano should store on your server's harddrive. This is handy in case you ever want to rollback to a previous version quickly in case your newly deployed code blew something up and you need to put out the fires. But you probably want this to be a finite number so you don't fill up your disk with inactive versions of your app. I keep five releases.

set :keep_releases, 5

Next, you should use the following setting to ensure any needed password prompts from SSH show up in your terminal so you can handle them.

default_run_options[:pty] = true

The last setting you need to handle is where on the internet Capistrano can find your server. This could be your domain name or the IP address. I'm assuming this deployment is for a smallish MVP-type app where everything is on the same machine (database, app, server, etc.). In this case you can use Capistrano's server setting.

server "www.example.com", :app, :web, :db, :primary => true

If you want to do fancier deployments by splitting things up for scaling (like separating your database from your application server), you'll want to use Capistrano's "roles" to point it to the different places where things are installed. Use multiple roles instead of the server command (it accomplishes the same thing with greater granularity).

role :web, "web.example.com"
role :app, "app.example.com"
role :db, "db.somethingelse.com", :primary => true

That :primary => true part of the database role tells Capistrano that this is the location of your primary database. Read more about this in greater detail.

Connect

Before we get into the individual deployment tasks, check that all the settings you've just saved in deploy.rb are working properly. Run this command in a terminal from your app's root.

cap deploy:setup

This will SSH to your server and create some directories in the folder you specified with deploy_to where Capistrano will store your releases, and your shared files (e.g., logs, configs, static assets like uploads, etc.). If something goes wrong with permissions or SSH access, you'll see some error messages. Fix these before proceeding so you know you can actually make a connection to your server.

This should setup the following directories (if you've specified to install your app in /var/www/example.com/):

/var/www/example.com/current
/var/www/example.com/shared
/var/www/example.com/releases

The /releasesdirectory is where copies of all your actual code are stored. /shared is a place where you can put common, shared files like logs, static assets, and in our case, config files like database.yml. /current is simply a symbolic link that points to the current release inside the /releases directory (Capistrano updates this for you on each deploy, so don't worry about it).

If deploy:setup works, the next thing you can do is run the deploy:check command. This will check your local environment and your server and try to locate any possible issues. If you see any errors, fix them first, and then run the command again until you don't have any more errors.

cap deploy:check

Any number of things could go wrong here, but the most likely issues will be some sort of authentication or file permission issues with your server and the user you're logging in with SSH (I've lost count of the number of times I've wanted to punch my computer due to some unknown error only to discover I had set the file permissions incorrectly).

Database.yml

Let's take a break here and talk about your database.yml file. If you've been following along, you excluded it from your repository by adding it to your .gitignore file. This is good (don't store sensitive data like passwords in your repository). However, when you run Capistrano to update your server, it only copies the files that are in your repository (and Rails actually needs to use that database.yml file to hook up to your server's database, unless you don't plan on storing any data whatsoever). So, the problem is: we need to get that config file onto the server somehow, securely, and make sure Rails knows where to find it.

There are many different solutions out there for handling this issue, but I always like to keep things simple so I understand what's going on without too much magic. For this, I just manually put the file on my server in a shared location that only I (and the app) have read-access to.

First, make a new /config directory in the /shared directory that Capistrano created.

ssh [email protected] -p 4321
mkdir /var/www/example.com/shared/config

Leave the server and back on your local machine, in your app's root directory, copy the database.yml file to the server (NOTE: unintuitively, you need to specify the port number with a capital P when using the scp command).

scp -P 4321 ./config/database.yml  [email protected]:/var/www/example.com/shared/config/database.yml

Note, the above command is one long line (in case it's wrapping in your browser).

I then hook it up to the app with a simple symbolic link that I create in my deployment script inside deploy.rb (see below).

Tasks

Now for the fun stuff. You can make all kinds of cool programming logic for different needs that you can run each time you deploy your app so it's all nicely automated (I like not thinking too hard).

I put all my deployment tasks under the "deploy" namespace inside my deploy.rb file. You could make up your own namespaces if you want, to help you organize things. But I'm just going to go over some basic stuff, so I'll group all these tasks under "deploy". The format of the tasks looks like this:

namespace :deploy do
  desc "Human readable description of task"
  task :name_of_task_command do
    # do stuff
  end
end

The string defined by the desc command is what will show up when you run cap -T from the CLI on your application (this lists all the deployment tasks available in your app).

The basic deployment tasks you need to accomplish are as follows:

1. Update application code
2. Precompile assets
3. Update custom symlinks
4. Restart the server
5. Cleanup unneeded files

I used to need to make custom tasks for a lot of this stuff, but lucky for you, these days most of this is baked into Capistrano to make your life that much easier! I'll go over each task one by one. You can also tack on other things you need to do on deploy (like refresh your sitemap, restart/reindex your search engine, etc.) but I'm just going to stick with the basics for now (this article is already crazy long!)

1. Update Application Code

You don't need a special task for this. This is Capistrano's primary function. When you run cap deploy it will first update your code. However, if you want to only update your code and not do anything else, you can use the cap deploy:update_code command to do it.

2. Precompile assets

Here's another freebie. I was handling asset compilation on my own until I started writing this article and discovered that this, too, is now baked into Capistrano (win). So instead of dealing with file-permission issues for generating asset files, all you have to do is uncomment this one line (that should already exist from when you capified your project) in the Capfile file.

load 'deploy/assets'

This tells Capistrano to precompile assets on each deploy (it's commented out because for some reason there are other people out there using Capistrano for projects built with different frameworks than Ruby on Rails and don't need to run this task; go figure).

However, I ran into a Rails 4 gotcha in that Capistrano barfs while looking for a file called /path-to-app/shared/assets/manifest.yml on your server (at least as of version 2.14.2 which I'm using). Rails has changed the format of the manifest file to use JSON now in the format of manifest-a5247d24f7c66d27d9b50f5c7e640bca.json. To get around this error, I simply created an empty version of the file Capistrano wants to see in the place it's looking for it. Read more about this issue.

On your remote server:

touch /path-to-your-app/shared/assets/manifest.yml

3. Update custom symlinks

This could be a link to some static assets you want to store outside your repository or something, but the main thing you need to do here is hook up your database.yml file so Rails can find it!

Rails expects to see /path/to/your/app/config/database.yml. But the file is now stored in /deploy_to/shared/config/database.yml. What to do? Here comes the magic of symbolic links. Add this task to your deploy.rb file.

desc "Symlink shared config files"
task :symlink_config_files do
  run "#{ try_sudo } ln -s #{ deploy_to }/shared/config/database.yml #{ current_path }/config/database.yml"
end

4. Restart the server

Since the server is setup to run with Phusion Passenger, you'll need to override Capistrano's default restart task with one specific to Passenger (i.e., you want to touch /tmp/restart.txt from inside your app's root. This is pretty simple by adding this task to the "deploy" namespace in deploy.rb.

  desc "Restart Passenger app"
  task :restart do
    run "#{ try_sudo } touch #{ File.join(current_path, 'tmp', 'restart.txt') }"
  end

5. Cleanup unneeded files

This one comes baked in too, but I just wanted to highlight it because I sometimes forget :P If you don't run cleanup, the worst thing that will happen is that all your old releases stay stored on your server. But you might not want this as it's taking up disk space. This task is run from deploy:cleanup.

After deploy

The final step in setting up your deployment script is to add your custom tasks to run after deployment (i.e., after all the files are copied to the server and the current_path has been updated to the latest release). All you need to do is tell Capistrano what tasks you want to run in the order you want to run them outside the deploy namespace block.

after "deploy", "deploy:symlink_config_files"
after "deploy", "deploy:restart"
after "deploy", "deploy:cleanup"

Since precompiling assets and updating the code are baked in, you don't need to specify those tasks. If you add any other tasks to your deployment process, you can just add them here to get executed.

Deploy!

Now to actually do stuff. You should have a remote Git repository with the latest version of your code in it, Capistrano setup and checked, and your deployment tasks written and ready to run. So let's run it:

cap deploy

Sit back and watch all those characters flow over your terminal and feel good inside knowing the computer is saving you hours of frustration (if you aren't frustrated already, haha).

If you need to simply migrate your database, Capistrano has a task for that too.

cap deploy:migrate

And if something goes horribly wrong (which will happen), you can quickly and easily rollback to the previous release (which is hopefully a working version).

cap deploy:rollback

Run this multiple times to go back through additional past releases.

Your regular routine can now be something like this:

1. change some stuff in your code
2. git add . it to your local repo queue
3. git commit -m 'my new commit' it to your local repo
4. git push origin master to sync it to your remote
5. cap deploy to update your production server with your changes
